2.50 Lac / Piece
| Business Type | Manufacturer, Exporter, Supplier |
| Material | Stainless Steel |
| Application | Industrial |
| Certification | CE Certified |
| Click to view more | |
Product Details
Type
Automatic
Country of Origin
India
Warranty
1 Year
Specifications
| Rated cutting capacity | 1,200 [Kn] | |||||||||||
| Conveying speed | 50 [m/min] | |||||||||||
| Cutting speed | 20 [times/min] | |||||||||||
| Cutting length | 750 – 120,000 [mm] | |||||||||||
| Cutting length tolerance | ±5 [mm] | |||||||||||
| Blade availability width | 200 [mm] | |||||||||||
| Min. length of remaining waste bars | 100 [mm] | |||||||||||
| Collecting pocket no° | 3*2 | |||||||||||
| Average power consumption | 8 [KW/h] | |||||||||||
| Dimension (L×W×H) | 25,800×3,200×1750 [mm] | |||||||||||
| Rebar diameter (max tensile strength 750Mpa) | 10 | 12 | 16 | 20 | 22 | 25 | 28 | 32 | 35 | 38 | ||
| Rebar cut no° | 10 | 8 | 6 | 4 | 3 | 3 | 2 | 1 | 1 | 1 | ||
Looking for "Automatic Rebar Shear Line Machine" ?
